380V PLC Control 50TPH RO Water Plant With RO System

Product Categories
Shenzhen Yajie Environmental Protection Equipment Co.,Ltd
Contact Now

380V PLC Control 50TPH RO Water Plant With RO System

Brand Name : AJIEWATER

Model Number : AJ

Certification : ISO9001, CE, SGS

Place of Origin : China

MOQ : 1 set

Price : Negotiation

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : >300sets/month

Delivery Time : 1-7working days(depand on raw materials stocking)

Packaging Details : export standard wooden case(plywood), no need to fumigate, suitable for shipping.

Capacity : 8~12 people

After-sales service provided : commissioning and training

Material : Wood

Power : 380V 50Hz 3 phase or customized

Weight : 350KG

Type : Seawater Desalination Equipment

Application : water water purification machines

Warranty : 2 Years

Contact Now

PLC Control Seawater Desalination System 50TPH Ro Water Plant With Ro System

Detailed Product Description

Process: Raw water pump - Sand filter - Carbon filter - water softener - Cartridge filter - High pressure pump-RO membrane host


Application: mineral water, direct drinking water, beverage&food,win.,ect
Water outlet: Conductivity <10us.cm25℃(support customize)
Production Capacity: 0.5m³ per hour

Name:

 50TPH Ro Water Plant With Ro System

Production Capacity:

 50TPH

Recovery Rate:

 50% - 75%

Electrical Power:

 380V 50Hz 3Phase (Customize Available)

Tank Material:

 FRP / Stainless Steel / Carbon Steel

Control Valve:

 Automatic / Manual

Pipe Fitting:

 SUS304 / SUS316L / U-PVC

Operating Temperature:

 5℃ - 39℃


PLC Control Seawater Desalination System 50TPH Ro Water Plant With Ro System

RO (Reverse Osmosis) Water Purification Treatment : The capacity ranges: from 1500GPD (0.25t/h) to 3,000,000 GPD (500t/h). Reverse osmosis (RO) technology known as hyper filtration, is widely used in Cosmetic, Pharmaceutical, chemical industries, food, drinking water. RO equipment is the most advance and energy saving in water treatment industry.

Brackish water from the water pump into the quartz sand (multi-media filter) and activated carbon filtration system filtration. Filtered water after water quality reduction, PH adjustment and scale inhibitor added after the access to the precision and security filtration system, filtered low pressure brackish water all the way into the high-pressure pump pressure, the other way into the pressure exchange energy recovery device, after pressurized pump pressurized with high pressure pump into the reverse osmosis membrane reactor system. High-pressure brackish water in the membrane reactor under the treatment of the formation of fresh water through the membrane after water quality adjustment into the fresh water tank storage. The rest of the high pressure concentrated water enters the pressure exchange energy recovery unit to recover the energy after discharge.

Process

Optional Components

A. Regulating wheels F. Auto or manual control valve
B. PC Touch Screen G. U-PVC or stainless steel pipe
C. Two-stage RO system H. UV sterilizer/Ozone Generator
D. PH adjustment I. Dosing system(anti-scale)/Water Softener
E. CIP cleaning system

J. PE or stainless steel raw/pure water tank

Features:

1. High and stable output water quality;
2. Output water continuously, do not regenerate due to stopping;
3. Do not need chemical regeneration;
4. Thoughtful stacked design, small occupy room
5. Simple and safe operation
6. Low operation and maintain cost
7. No acid and alkali in stock and transportation fee
8. Totally automatic operation, do not need mens attention


Advantages:

1. Fresh water quality, transparent processing, clean, health, and meet GB requirements
2. High technical, stable operation, easy to maintain, long life time
3. We can design upon customers requirement
4. Competitive price, more profit

Applications:

1. Medical production,industrial pharmacy use
2. Cosmetics
3. Recycling water system
4. Chemical, electroplate industrial etc
5. Microelectronic, power, and biological project
6. Chemical Lab
7. Other electronic standard water


Buying process:
